IR-force 200 analyzer parameters:

Model: IR-force 200

Collector channels:two channel (diagnosis one set samples)

Built-in printer: Yes (no external printer required)

Computer connection: can be used stand-alone

Warm-up time: 15 minutes

Sample volume:exhale air to the full air bag

Power supply: A.C 220V, 50Hz

Input power: 60VA

Analyzer Dimensions (L*W*H) (mm): 400*200*300

IR-force 200 Analyzer advantages:

Quality control: calibration, positive gas quality control to ensure equipment accuracy;

Precision: δsd does not exceed 0.6‰

Stability: The absolute value of C.V. is not greater than 3%

Analysis speed: each sample analysis time <180s

Detection sensitivity: CO2 minimum detection concentration: 0.5%

Measuring range: CO2 concentration 1%~10%

working condition:

Power supply: a.c 220V±22V, 50Hz±1Hz

Altitude: below 2000m

Ambient temperature: 10°C~30°C

Relative humidity: no more than 70%

Atmospheric pressure: 86kPa~106kPa

Software function:

The functions of the special software for 13c urea breath test analyzer should include: user login, user management, sample testing, point report, information query, data statistics, self-test, correction, quality control and other functions.

Detection principle：

After the subject took 13C urea by mouth, the urease produced by Helicobacter pylori will decompose the 13C urea into 13C carbon dioxide and ammonia. The 13C  dioxide enters the lungs through the blood and is exhaled from the body. Collect the subject's exhaled breath and detect the change of 13C/12C carbon dioxide ratio in the exhaled breath with an infrared spectrometer to diagnose Helicobacter pylori infection in the stomach.
